MAGBED MB Series
"Standard Lineup for Various Machining Environments" A modular configuration that serves as the foundation for customized expansion
- A proprietary basic module combining precision and stability
Product Information
MAGBED is a permanent magnet workholding system designed for use in a variety of machining environments.
MAGBED MB Series
Product Details
MAGBED MB Series
Product Parameters
◀ Swipe the table left or right to see the full contents ▶
| Model | Size (mm) | Protection Block 52X52 (mm) | Weight (kg) |
|---|---|---|---|
| MB35 | 125 X 305 X 115 | 8 | 31 |
| MB40 | 125 X 367 X 115 | 10 | 38 |
| MB45 | 125 X 430 X 115 | 12 | 43 |
| MB50 | 125 X 492 X 115 | 14 | 50 |
| MB55 | 125 X 555 X 115 | 16 | 57 |
MAGBED MB Series
Product Features
MB Series
The Beginning of MAGBED
Standard Lineup for Various Machining Environments
A modular configuration that serves as the foundation for customized expansion
◆ A proprietary basic module combining precision and stability
A standard workholding solution that contains the essence of our MAGBED technological expertise.
The Five (5) model lineup (MB35, MB40, MB45, MB50, and MB55) was expanded to provide a wider range of options to suit the intended application and workpiece specifications.
Designed to provide a stable and reliable machining environment for small-to-medium-sized machining applications.
1. Long-Lasting Magnetic Force
• Features ultra-strong magnetic force exceeding comparable products, and provides a semi-permanent service life without significant loss of magnetic force.
2. 5-Year Quality Warranty
• The product is backed by a 5-year quality warranty based on its excellent durability and magnetic force retention.
3. Minimized Components, Easy Maintenance
• The durability-focused design minimizes the number of components and significantly reduces the possibility of failure. When a consumable component, such as a protective block, becomes worn, only the individual block needs to be replaced and maintenance is made more efficient.
4. Expedited Delivery Within 72 Hours
• The proprietary assembly design enables expedited delivery within 72 hours after an order is placed.
